B–63173EN–1/01

1. AXIS CONTROL

1936 Connector number for first pulse module

1937 Connector number for second pulse module

[Data type] Byte axis

[Valid data range] 0 to 7

To use a pulse module, this parameter must be set to “connection number

for the pulse module,” minus 1; that is, 0 for connector number 1, 1 for

connector number 2, and so on. It is also necessary to set up bits 6 and

7 of parameter No. 1905. For an axis that does not use a pulse module,

0 is specified for the parameter. Basically, each axis can be combined with

any connector, but the smaller connector numbers must be used first. For

example, connector number 4 cannot be used unless connector number 3

is in use.

Example)

Controlled

axis

Connector

number for

first pulse

module

Connector

number for

second pulse

module

No.1936 No.1937

No.1905

(#7, #6)

X 1 Not used 0 0 0,1

Y Not used 2 0 1 1,0

Z Not used 1 0 0 1,0

A Not used Not used 0 0 0,0

B 2 Not used 1 0 0,1

C Not used 3 0 2 1,0

If the FSSB setting mode is automatic setting (bit 0 of parameter No. 1902

= 0), this parameter is set automatically when data is entered using the

FSSB setting screen. For manual setting 2 (bit 0 of parameter No. 1902

= 1), the user must set this parameter.

Number Message Description

460 n AXIS : FSSB DISCON-

NECT

FSSB communication was interrupted.

The most likely causes are:

1. The FSSB communication cable is

disconnected or has a broken con-

ductor.

2. The amplifier power supply was

turned off.

3. A low–voltage alarm condition oc-

curred in the amplifier.

461 n AXIS : ILLEGAL AMP

INTERFACE

The fast type interface was assigned to

both axes of a two–axis amplifier.

462 n AXIS : SEND CNC

DATA FAILED

The slave could not receive data cor-

rectly because of an FSSB commu-

nication error.

Alarm and message

D Servo alarms
