B–63173EN–1/01

1. AXIS CONTROL

#7 #6 #5 #4 #3 #2 #1 #0

IPR1004

IPR

ISC

ISA

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

[Data type] Bit

ISA, ISC The least input increment and least command increment are set.

ISC ISA Least input increment and

least command increment

Symbol

0 0 0.001mm, 0.001deg, or 0.0001inch IS-B

0 1 0.01mm, 0.01deg, or 0.001inch IS-A

1 0 0.0001mm, 0.0001deg, or 0.00001inch IS-C

NOTE

1 The IS–A cannot be used in the Power Mate i–D.

2 The IS–C cannot be used in the Power Mate i–H.

IPR Whether the least input increment for each axis is set to a value 10 times as

large as the least command increment is specified, in increment systems

of IS–B and IS–C, mm input.

0 : The least input increment is not set to a value 10 times as large as the

least command increment.

1 : The least input increment is set to a value 10 times as large as the least

command increment.

If IPR is set to 1, the least input increment is set as follows:

Input increment Least input increment

IS-B 0.01 mm, 0.01 deg, or 0.0001 inch

IS-C 0.001 mm, 0.001 deg, or 0.00001 inch

NOTE

For IS–A, the least input increment cannot be set to a value

10 times as large as the least command increment.

When inch of input is specified, the least input increment

does not become 10 times as large as the least command

increment.

OPERATOR’S MANUAL

(B–63174EN)

II.2.3 Increment System

Reference item
