9. SPINDLE SPEED FUNCTION

384

3705

SFA

NSF

#4 #3

SGT

#2 #1 #0

ESF

[Data type] Bit

ESF When the spindle control function (S analog outpu or S serial output) is

used, and the consatant surface speed control function is used or bit 7

(GTT) of parameter No. 3705 is set to 1:

0 : S codes and SF are output for all S commands.

1 : S codes and SF are not output for an S command in constant surface

speed control mode (G96 mode) or for an S command used to specify

maximum spindle speed clamping (G50S–––;).

NOTE

In the following cases, SF is not output:

· For an S command used to specify maximum spindle

speed clamping (G92S–––;) in constant surface speed

control mode

· When bit 5 (NSF) of parameter No. 3705 is set to 1

SGT Gear switching method during tapping cycle (G84, G74)

0 : Method A (Same as normal gear switching method)

1 : Method B (Gears are switched during tapping cycle according to the

spindle speed set in parameters 3761 and 3762)

NSF: When an S code command is issued in constant surface–speed control,

0 : SF is output.

1 : SF is not output:

SFA: The SF signal is output:

0 : When gears are switched

1 : Irrespective of whether gears are switched
