POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 1024

Connection manual (Function)

Page of 1173

/ 1173

EDIT

DATE DESIG

DESCRIPTION

FANUC LTD

B-63173EN-1/01-28

DRAW.NO.

CUST

TITLE

FANUC Power Mate i -MODEL H

CONNECTION MANUAL(FUNCTION)

M-code direct output function

(High Response Function)

14/16

SHEET

Data no Data

7420 Number of output bits 1 for direct signal output

7421 Number of output bits 2 for direct signal output

7422 Number of output bits 3 for direct signal output

(Data type): Byte

(Valid data range): 1-8

Set the number of output bits on Y address.

Ex) When the output address is Y1001 and the number

of output bits is 3, then Y1001#0 to #2 are used for direct

signal output.

The correspondence between M-code and these

parameters are shown below.

No.7420 corresponds to No.7410

No.7421 corresponds to No.7411

No.7422 corresponds to No.7412

If this parameter is set to “0”, the M-code corresponded

to the parameter is not used for direct signal output.

Note) When this parameter is set, the power must be

turned off before operation is continued.

These parameters are effective only in case of direct

signal output function.

CautionCaution

As the output signals on the built-in I/O are used, the address and the

bit of the direct signal must not overlap with the other usage of PMC

application. The signals that are already used for other purpose cannot

be assigned here.

The bits other than the direct signal in the address assigned for the

direct signal must not be used for other usage.
