15. PMC CONTROL FUNCTION

B–63173EN–1/01

552

#7 #6 #5 #4 #3 #2 #1 #0

G000

G001

G002

ED7 ED6 ED5 ED4 ED3 ED2 ED1 ED0

ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8

ESTB EA6 EA5 EA4 EA3 EA2 EA1 EA0

F060

ESEND EREND

#7 #6 #5 #4 #3 #2 #1 #0

3202

PSR

#5 #4 #3 #2 #1 #0

[Data type] Bit type

PSR Search for the program number of a protected program

0 : Disabled

1 : Enabled

6300

#6 #5 #4

ESR

#3 #2 #1 #0

[Data type] Bit type

ESR External program number search

0 : Disabled

1 : Enabled

Number Message Description

059 PROGRAM NUMBER

NOT FOUND

In an external program number search

or external workpiece number search,

a specified program number was not

found. Otherwise, a program specified

for searching is being edited in back-

ground processing. Check the program

number and external signal. Or discon-

tinue the background eiting.

Signal address

Parameter

Alarm and Message
