B–63173EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

637

Function

Refer-

ence

–HPM

–DAddressSymbolSignal name

Spindle serial

output/spindle analog

output

Output switch completion

signals (serial spindle)

RCFNA F046#3 f –

Subordinate operation status

signals (serial spindle)

SLVSA F046#4 f –

Position coder orientation

proximity signal (serial

spindle)

PORA2A F046#5 f –

Spindle serial

out

ut/s

indle analog

Magnetic sensor orientation

completion signals (serial

spindle)

MORA1A F046#6 f –

9.2

e ana

output

Magnetic sensor orientation

proximity signals (serial

spindle)

MORA2A F046#7 f –

Position coder one–rotation

signal detection status

signals (serial spindle)

PC1DEA F047#0 f –

Incremental orientation mode

signals (serial spindle)

INCSTA F047#1 f –

Spindle stop signal *SSTP G029#6 f –

Spindle orientation signal SOR G029#5 f –

Gear shift signal GST G212#5 f –

Spindle speed override

signals

SOV0 to SOV7 G030 f –

Spindle speed

control

Spindle speed arrival signal SAR G029#4 f –

9.3

con

Spindle enable signal ENB F001#4 f –

9.3

Gear selection signals

(output)

GR1O,GR2O,GR3

F034#0 to #2 f –

Gear selection signals (input) GR1,GR2 G028#1,#2 f –

S12–bit code signals R01O to R12O

F036#0 to

F037#3

f –

HS1A to HS1D G018#0 to #3 f f

Manual handle feed axis

selection signals

HS2A to HS2D G018#4 to #7 f f

Manual handle feed

selection

signals

HS3A to HS3D G019#0 to #3 – f

3.2

Manual handle feed amount

selection signals (incremental

feed signals)

MP1,MP2 G019#4,#5 f f

HS1IA to HS1ID G041#0 to #3 f f

Manual handle

interrupt

Manual handle interrupt axis

selection signals

HS2IA to HS2ID G041#4 to #7 f f

3.3

interru t

selection

signals

HS3IA to HS2ID G042#0 to #3 – f
