Note

・ In case of the application of absolute encoder, the parameter No.2229#0

is set to “1” and the pole position detection is executed once, after the

pole position detection is completed, this signal can keep the condition of

“1” even if the power is turned off and on. If the parameter No.2139 is set

to “0” and the power is turned off and on, this signal becomes “0”.

・ In case of the application of incremental encoder, the pole postion

detection completion signal don’t become “0” unless the power is turned

off.

Signal Address

#7 #6 #5 #4 #3 #2 #1 #0

G135 RPRE

8 RPRE

7 RPRE

6 RPRE

5 RPRE

4 RPRE

3 RPRE

2 RPRE

#7 #6 #5 #4 #3 #2 #1 #0

F158 RPDET8 RPDET7 RPDET6 RPDET5 RPDET4 RPDET3 RPDET2 RPDET1

F159 RPFIN8 RPFIN7 RPFIN6 RPFIN5 RPFIN4 RPFIN3 RPFIN2 RPFIN1

Alarm and message

Number Message Description

454

nAXIS:ILLEGAL ROTOR POS

DETECT

The pole position detection stops illegally.

The pole position can not be detected because motor

can not move.

B-63173EN-1/01-41

Edit

Apprv.

Desig.

Sheet

Title

Draw

No.

9/9

Date

Design

Descri

tion

Date

FANUC Power Mate i-MODEL D/H

Pole Position Detection Function
