#7 #6 #5 #4 #3 #2 #1 #0

8653 CM3 CM2 CM1

[Data type] Bit

CM1 When the [CUSTOM/GRAPH] key is pushed, the user screen that was defined as

CRT_USR_AUX

0: Is not displayed.

1: Is displayed.

CM2 When the [CUSTOM/GRAPH] key is pushed, the user screen that was defined as

CRT_USR_MCR

0: Is not displayed.

1: Is displayed.

CM3 When the [CUSTOM/GRAPH] key is pushed, the user screen that was defined as

CRT_USR_MENU

0: Is not displayed.

1: Is displayed.

Symbols in a source file set which user screen is displayed. The following table shows

relation between symbols and parameters.

Parameter

mbol

CM1 CRT_USR_AU

CM2 CRT_USR_MCR

CM3 CRT_USR_MENU

The symbols mean following screens.

• CRT_USR_AUX: a screen displayed with a push of [CUSTOM/GRAPH] key.

• CRT_USR_MCR: a screen displayed with twice push of [CUSTOM/GRAPH] key.

• CRT_USR_MENU: a screen displayed with three times push of [CUSTOM/GRAPH]

key.

These screens are changed with a push of [CUSTOM/GRAPH] key. The screens, which

correspond to the parameters with 0, are skipped.

NOTE

If you have Macro Executor option, these parameters are invalid.
