B–63173EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

273

1624

Time constant of exponential acceleration/deceleration, bell–shaped

acceleration/deceleration after interpolation or linear acceleration/

deceleration after interpolation, in jog feed for each axis.

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000 (For exponential acceleration/deceleration)

0 to 8192 (For linear acceleration/deceleration after interpolation or

bell–shaped acceleration/deceleration after interpolation)

Set the time constant used for exponential acceleration/deceleration, bell

shaped acceleration/deceleration after interpolation or linear

acceleration/deceleration after interpolation in jog feed for each axis.

The type of acceleration/deceleration is determined depending on the

setting in parameter No. 1610.
