POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 25

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

1. AXIS CONTROL

[Classification] Output signal

[Function] These signals notify the PMC that the corresponding axes have been

released from control.

These signals are provided for each control axis; the affixed number of the

signal name shows the control axis number.

1 ..... The 1st axis is detached.

2 ..... The 2nd axis is detached.

8 ..... The 8th axis is detached.

MDTCH 1

[Output condition] These signals are 1 in the following case:

– When the corresponding axes are released from control

These signals are 0 in the following case:

– When the corresponding axes are under control

#7 #6 #5 #4 #3 #2 #1 #0

DTCH8G124 DTCH7 DTCH6 DTCH5 DTCH4 DTCH3 DTCH2 DTCH1

MDTCH8F110 MDTCH7 MDTCH6 MDTCH5 MDTCH4 MDTCH3 MDTCH2 MDTCH1

#7 #6 #5 #4 #3 #2 #1 #0

RMVx0012

Setting entry is acceptable.

[Data type] Bit axis

RMVx Releasing the assignment of the control axis for each axis

0 : Not released

1 : Released

NOTE

RMVx is valid when RMBx in parameter 1005 is 1.

#7 #6 #5 #4 #3 #2 #1 #0

RMBx1005

[Data type] Bit axis

RMBx Releasing the assignment of the control axis for each axis (signal input

and setting input)

0 : Invalid

1 : Valid

Controlled axis detach

status signals

MDTCH1 – MDTCH8

<F110>

Signal address

Parameter
