・ When the incremental encoder is used too with No.2229#0(ABSEN)=1, the result of pole

positon detection is memorized to No.2139 (AMR offset) after the pole position detection is

completed and one rotation signal in encoder is caught. This suppresses change of the torque

constant by the variation in pole position detection.

Note

・ When the incremental encoder is used, the result of pole positon

detection is memorized just after one rotation signal in encoder is caught.

Accordingly, even if the pole position detection is executed, the result of

pole position detection is not memorized when the power is turned off

before one rotation signal in encoder is caught

・ When the incremental encoder is used, the result of pole position

detection memorized in the parameter No.2139 (AMR offset) is effective

in servo control after one rotation signal in encoder is caught.

Accordingly, the torque constant may be changed by the variation in pole

position detection until one rotation signal in encorder is caught.

B-63173EN-1/01-41

Edit

Apprv.

Desig.

Sheet

Title

Draw

No.

5/5

Date

Design

Descri

tion

Date

FANUC Power Mate i-MODEL D/H

Pole Position Detection Function
