B–63173EN–1/01

2. PREPARATIONS FOR OPERATION

130

[Classification] Output signal

[Function] This signal indicates that P/S alarm or custom macro alarm has occurred.

[Output condition] The signal becomes 1 if:

– P/S alarm (No.001 to 099, 102, 102 to 254) or cuctom macro alarm

occurs.

The signal is 0 if:

– P/S alarm (No.001 to 099, 102, 102 to 254) or cuctom macro alarm

has not occurred.

[Classification] Output signal

[Function] This signal indicates that over travel alarm has occurred.

[Output condition] The signal becomes 1 if:

– Over travel alarm occurs.

The signal is 0 if:

– Over travel alarm has not occurred.

[Classification] Output signal

[Function] This signal indicates that over heat alarm has occurred.

[Output condition] The signal becomes 1 if:

– Over heat alarm occurs.

The signal is 0 if:

– Over heat alarm has not occurred.

[Classification] Output signal

[Function] This signal indicates that servo alarm has occurred.

[Output condition] The signal becomes 1 if:

– Servo alarm occurs.

The signal is 0 if:

– Servo alarm has not occurred.

P/S Alarm signal ALPS

<F250#3>

Over travel alarm signal

ALOT <F250#4>

Over heat alarm signal

ALOH <F250#5>

Servo alarm signal ALSV

<F250#6>
