POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 1163

Connection manual (Function)

Page of 1173

/ 1173

EDIT

DATE DISIGNE

DESCRIPTION

TITLE

DRAW

FANUC Power Mate i - MODEL D/H

Status display for PMC axis control

B-63173EN-1/01-44

SHEET

2/ 8

APPROV.

FANUC LTD

050727 01

New design

15.1.4

Status display for PMC axis control

General

The buffer status of PMC axis control and the axis status for PMC axis

control can be displayed on CRT.

Specification

1. Press function key SYSTEM

2. Press the continuous menu key , then press chapter selection

soft key [PMCAXS].

The following screen ( Signal status screen ) is displayed:

Add the description as "15.1.4 Status display for PMC axis control "

PMC AXIS CONTROL O0001 N00001

(SIGNAL STATUS) X AXIS Y AXIS

ALARM SIGNAL 0 0

RESET SIGNAL 0 0

AXIS MOVE SIGNAL 0 0

ECKZ SIGNAL 0 0

INPOS SIGNAL 1 1

AXIS STOP SIGNAL 0 0

DISTANCE TO GO -12345678 -12345678

MDI **** *** *** 12:00:00

[ ][ ][PMCAXS][ ][(OPRT)]
