B–63173EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

282

1784

Feedrate when overtravel alarm has generated during

acceleration/deceleration before interpolation

[Data type] Word

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 – 15000 6 – 12000

Inch machine 0.1 inch/min 6 – 6000 6 – 4800

Deceleration is started beforehand to reach the feedrate set in the

parameter when an overtravel alarm is issued (when a limit is reached)

during linear acceleration/deceleration before interpolation. By using

this parameter, the overrun distance that occurs when an overtravel alarm

is output can be reduced.

WARNING

The control described above is applicable only to stored

stroke limit 1.

NOTE

1 When 0 is set in this parameter, the control described above

is not exercised.

2 Use type–B linear acceleration/deceleration before

interpolation (by setting bit 0 (FWB) of parameter No. 1602

to 1).

[Unit of data]

[Valid data range]
