POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 60

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

1. AXIS CONTROL

D AMP amplifier type. . . .

The amplifier type display consists of the letter A, which stands for

“amplifier”, a number that indicates the placing of the amplifier, as

counted from that nearest to the CNC, and a letter such as L (first

axis) or M (second axis) indicating the placing of the axis in the

amplifier.

D AXIS controlled axis number. . . .

The axis number of each controlled axis specified in parameters

(Nos. 1920 to 1929) is displayed. If a number specified in these

parameters falls outside the range of between 1 and the maximum

number of controlled axes, 0 is displayed.

D NAME controlled axis name. . .

The axis name assigned to a parameter (No. 1020) corresponding

to a particular controlled axis number is displayed. If the controlled

axis number is 0, – is displayed.

D The following items are displayed as amplifier information:

S UNIT servo amplifier unit type. . . . .

S SERIES servo amplifier series. . .

S CUR. maximum rating current. . . . .

D The following items are displayed as pulse module information:

S EXTRA

This display consists of the letter M, which stands for “pulse

module”, and a number indicating the placing of the pulse

module, as counted from that nearest to the CNC.

S TYPE

This display is a letter indicating the type of the pulse module.

S PCB ID

This display consists of four digits indicating the pulse module

ID (hexadecimal). The pulse module ID is followed by

DETECTOR (8AXES) when 8–axes pulse module or

DETECTOR (4AXES) when 4–axes pulse module.

(2)Axis setting screen

The axis setting screen displays the information shown below:

AXIS SETTING O1000 N00001

AXIS NAME AMP M1 M2 1–DSP CS TNDM

1 X A1–L 0 0 001

2 Y A1–M 1 0 1 0 0

3 Z A2–L 0 0 0 1 0

4 A A3–L 0 0 0 0 2

5 B A3–M 0 0 0 0 0

6 C A4–L 0 0 0 0 0

MDI **** *** *** 13:11:56

[ AMP ][ AXIS ][ MAINTE ][ ][ (OPRT) ]

The axis setting screen displays the following items:
