POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 558

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

15. PMC CONTROL FUNCTION

545

8005

#6 #5 #4 #3

DRR

R10

#1 #0

[Data type] Bit

R10 When the RPD parameter (bit 0 of parameter No.8002) is set to 1, the unit

for specifying a rapid traverse rate for the PMC axis is:

0 : 1 mm/min.

1 : 10 mm/min.

DRR For cutting feed per rotation in PMC axis control, the dry run function is:

0 : Disabled.

1 : Enabled.

8010 Selection of the DI/DO group for each axis controlled by the PMC

[Data type] Byte axis

[Valid data range] 1 to Number of Controlled axes

Specify the DI/DO group to be used to specify a command for each

PMC–controlled axis.

Value Description

1 DI/DO group A (G142 to G149) is used.

2 DI/DO group B (G154 to G161) is used.

3 DI/DO group C (G166 to G173) is used.

4 DI/DO group D (G178 to G185) is used.

5 DI/DO group E (G464 to G471) is used.

6 DI/DO group F (G476 to G483) is used.

7 DI/DO group G (G488 to G495) is used.

8 DI/DO group H (G500 to G507) is used.

NOTE

If another value is specified, the axis is not PMC–controlled.

8022 Maximum feedrate for feed per rotation along a PMC–controlled axis

[Data type] Word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotaion axis 1 deg/min 6 to 15000 6 to 12000

Specify the maximum feedrate for feed per rotation along a PMC–con-

trolled axis

NOTE

The maximum feedrate set to first axis is valid to all axes.

The data of after second axis are invalid.

[Unit of data]

[Valid data range]
