POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 147

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

2. PREPARATIONS FOR OPERATION

134

[Output condition] The signal becomes 1 if:

– APC pulse miss error occurs.

The signal is 0 if:

– APC pulse miss error has not occurred.

[Classification] Output signal

[Function] This signal indicates that APC battery voltage 0 error (alarm 306) has

occurred.

1 APC battery volatge 0 error of 1st axis

2 APC battery volatge 0 error of 2nd axis

: :

A P B Z 1

[Output condition] The signal becomes 1 if:

– APC battery voltage 0 error occurs.

The signal is 0 if:

– APC battery voltage 0 error has not occurred.

[Classification] Output signal

[Function] This signal indicates that APC battery low alarm 1 (alarm 307) has

occurred.

1 APC battery low alarm 1 of 1st axis

2 APC battery low alarm 1 of 2nd axis

: :

A P B V 1

[Output condition] The signal becomes 1 if:

– APC battery low alarm 1 occurs.

The signal is 0 if:

– APC battery low alarm 1 has not occurred.

APC battery voltage 0

error signal APBZn

<F236#5 to F243#5>

APC battery low alarm 1

signal APBVn <F236#6 to

F243#6>
