B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 143 -
3128 Retracement time for deleting alarm data from the alarm history
[Input type] Parameter input
[Data type] Word path
[Unit of data] sec
[Valid data range] 0 to 255
From the alarm history, the alarm data that occurred during a set
period of time back from the power-off time is deleted.
When 0 is set, a retracement time of 1 second is assumed to be
specified.
#7 #6 #5 #4 #3 #2 #1 #0
MRE DAP DRP
3129
MRE
[Input type] Parameter input
[Data type] Bit path
# 0 DRP For relative coordinate display:
0: The actual position considering a tool offset (tool movement) is
displayed.
1: The programmed position excluding a tool offset (tool
movement) is displayed.
# 1 DAP For absolute coordinate display:
0: The actual position considering a tool offset (tool movement) is
displayed.
1: The programmed position excluding a tool offset (tool
movement) is displayed.
# 2 MRE When mirror image is used, relative coordinates are:
0: Updated with respect to the machine coordinates.
1: Updated with respect to the absolute coordinates.
Set this parameter to 1 when handling relative coordinates in the same
way as for the lathe system of the FS16i/18i/21i.
3131 Subscript of axis name
[Input type] Parameter input
[Data type] Byte axis
[Valid data range] 0 to 9, 65 to 90
In order to distinguish axes under parallel operation, synchronization
control, and tandem control, specify a subscript for each axis name.
Setting value Meaning
0
Each axis is set as an axis other than a parallel axis,
synchronization control axis, and tandem control
axis.
1 to 9 A set value is used as a subscript.
65 to 90 A set letter (ASCII code) is used as a subscript.
