4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 408 -
# 6 A53 So far, if a slanted axis is singly specified by a machine coordinate
command (G53) in angular axis control, this parameter set to 0
specifies that "compensation is applied to the Cartesian axis", and this
parameter set to 1 specifies that "a movement is made along the
slanted axis only". However, the specification has been changed so
that "a movement is made along the slanted axis only", regardless of
whether this parameter is set to 0 or 1.
# 7 ADG The contents of diagnostic data Nos. 306 and 307 are:
0: Not swapped. The slanted axis and Cartesian axis are displayed
in this order.
1: Swapped. The Cartesian axis and slanted axis are displayed in
this order.
8210 Slant angle of a slanted axis in angular axis control
[Input type] Parameter input
[Data type] Real path
[Unit of data] Degree
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] -180.000 to 180.000. However, angular axis control is disabled in the
ranges -95.000 to -85.000 and 85.000 to 95.000 (in the case of IS-B).
8211 Axis number of a slanted axis subject to angular axis control
8212 Axis number of a Cartesian axis subject to slanted axis control
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Word path
[Valid data range] 1 to number of controlled axes
When angular axis control is to be applied to an arbitrary axis, these
parameters set the axis numbers of a slanted axis and Cartesian axis.
If 0 is set in either of the two parameters, the same number is set in the
two parameters, or a number other than the controlled axis numbers is
set in either of the two parameters, a slanted axis and Cartesian axis
are selected as indicated in the following table:
Slanted axis Cartesian axis
M
series
Y-axis (axis with 2 set in
parameter No. 1022) of the
basic three axes
Z-axis (axis with 3 set in
parameter No. 1022) of the basic
three axes
T
series
X-axis (axis with 1 set in
parameter No. 1022) of the
basic three axes
Z-axis (axis with 3 set in
parameter No. 1022) of the basic
three axes
