B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 279 -
5350
Positional deviation limit imposed during tapping axis movement in rigid
tapping (second spindle)
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] Detection unit
[Valid data range] 0 to 99999999
This parameter sets a positional deviation limit imposed during
tapping axis movement in rigid tapping using the second spindle.
5352
Positional deviation limit imposed while the tapping axis is stopped in rigid
tapping (second spindle)
[Input type] Parameter input
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter is used to set a positional deviation limit imposed
while the tapping axis is stopped in rigid tapping using the second
spindle.
5354
Positional deviation limit imposed during tapping axis movement in rigid
tapping (third spindle)
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] Detection unit
[Valid data range] 0 to 99999999
This parameter sets a positional deviation limit imposed during
tapping axis movement in rigid tapping using the third spindle.
5356
Positional deviation limit imposed while the tapping axis is stopped in rigid
tapping (third spindle)
[Input type] Parameter input
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter is used to set a positional deviation limit imposed
while the tapping axis is stopped in rigid tapping using the third
spindle.
