4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 428 -
#7 #6 #5 #4 #3 #2 #1 #0
8512 A08 A07 A06 A05 A04 A03 A02 A01
#7 #6 #5 #4 #3 #2 #1 #0
8513 A16 A15 A14 A13 A12 A11 A10 A09
[Input type] Parameter input
[Data type] Bit path
A01 to A16 These parameters set the passing direction in which each
corresponding high-speed position switch is turned on.
The following table shows the correspondence between the bits and
switches.
The settings of each bit have the following meaning:
0: The high-speed position switch is turned on when the tool passes
through the coordinates for turning the switch on in the negative
(-) direction.
1: The high-speed position switch is turned on when the tool passes
through the coordinates for turning the switch on in the positive
(+) direction.
Parameter Switch
A01 1st high-speed position switch
A02 2nd high-speed position switch
A03 3rd high-speed position switch
: :
A16 16th high-speed position switch
#7 #6 #5 #4 #3 #2 #1 #0
8516 B08 B07 B06 B05 B04 B03 B02 B01
#7 #6 #5 #4 #3 #2 #1 #0
8517 B16 B15 B14 B13 B12 B11 B10 B09
[Input type] Parameter input
[Data type] Bit path
B01 to B16 These parameters set the passing direction in which each
corresponding high-speed position switch is turned off.
The following table shows the correspondence between the bits and
switches.
The settings of each bit have the following meaning:
0: The high-speed position switch is turned off when the tool passes
through the coordinates for turning the switch off in the negative
(-) direction.
1: The high-speed position switch is turned off when the tool passes
through the coordinates for turning the switch off in the positive
(+) direction.
Parameter Switch
B01 1st high-speed position switch
B02 2nd high-speed position switch
B03 3rd high-speed position switch
