B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 435 -
4.61 PARAMETERS OF THE INCORRECT OPERATION
PREVENTION FUNCTION
10000 Lower limit 1 of tool offsets No.01
to to
10019 Lower limit 1 of tool offsets No.20
[Input type] Parameter input
[Data type] Real path
[Unit of data] mm, inch, degree (input unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 to +999999.999)
These parameters set the lower limits of the following offset values:
- T series, without tool geometry/wear offsets, X-axis offset
- T series, with tool geometry/wear offsets, X-axis and geometry
offsets
- M series, tool offset memory A offset
- M series, tool offset memory B and geometry offsets
- M series, tool offset memory C, geometry, and length offsets
10020 Upper limit 1 of tool offsets No.01
to to
10039 Lower limit 1 of tool offsets No.20
[Input type] Parameter input
[Data type] Real path
[Unit of data] mm, inch, degree (input unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 to +999999.999)
These parameters set the upper limits of the following offset values:
- T series, without tool geometry/wear offsets, X-axis offset
- T series, with tool geometry/wear offsets, X-axis and geometry
offsets
- M series, tool offset memory A offset
- M series, tool offset memory B and geometry offsets
- M series, tool offset memory C, geometry, and length offsets
