30i/300i/300is-Model A, 31i/310i/310is-Model A and A5, Parameter manual Page 499

Parameter manual
B-63950EN/02 4.DESCRIPTION OF PARAMETERS
- 487 -
13242 Number of columns of the first cartridge (when the cartridge is of the matrix
type)
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Word
[Valid data range] 0 to 1000
When the first cartridge is of the matrix type (bit 0 (MT1) of
parameter No. 13240 is set to 1), set the number of columns in the pot
in this parameter. The setting must satisfy the following condition,
however: The sum total of the value obtained by (setting of
parameter No. 13241) × (setting of parameter No. 13242) and the
number of pots of other cartridges should not exceed 64 (1000 at
maximum). If this condition is not satisfied or this parameter is set to
0, the first cartridge is invalid.
13243 Number of rows of the second cartridge (when the cartridge is of the matrix
type)
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Word
[Valid data range] 0 to 1000
When the second cartridge is of the matrix type (bit 1 (MT2) of
parameter No. 13240 is set to 1), set the number of rows in the pot in
this parameter. The setting must satisfy the following condition,
however: The sum total of the value obtained by (setting of
parameter No. 13243) × (setting of parameter No. 13244) and the
number of pots of other cartridges should not exceed 64 (1000 at
maximum). If this condition is not satisfied or this parameter is set to
0, the second cartridge is invalid.
