4.DESCRIPTION OF PARAMETERS B-63950EN/02

- 374 -

[Input type] Parameter input

[Data type] 2-word axis

[Unit of data] Detection unit

[Valid data range] 1 to 999999999

This parameter sets the number of pulses from the position detector

per EGB slave axis rotation.

Set the number of pulses output by the detection unit.

Set this parameter when using the G81.5 EGB synchronization

command.

The method for setting parameters Nos. 7782 and 7783 is the same as

for parameters Nos. 7772 and 7773. For the method, see the

description of parameters Nos. 7772 and 7773.

The ratio of the number of pulses for the master slave to that of pulses

for the slave axis may be valid, but the settings of the parameters may

not indicate the actual number of pulses. For example, the number of

pulses may not be able to be divided without a remainder for the

reason of the master and slave axis gear ratios as described in example

2. In this case, the following methods cannot be used for the G81.5

command:

G81.5 T

C ; When the speed is specified for the master axis

and the travel distance is specified for the slave axis

G81.5 P

C0 L ; When the number of pulses is specified

for the master axis and the speed is specified for the slave axis
