FANUC Series 30i/31i/32i -A, 31i - A5
GRINDING CANNED CYCLE
(FOR GRINDING MACHINE)
041118
Grinding axis number in Traverse Grinding Cycle(G71)
5176
Grinding axis number in Plunge Grinding Cycle(G75)
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 0 to Number of controlled axes
For the Lathe system:
Set the Grinding axis number of Traverse Grinding Cycle(G71).
For the Machining Center system:
Set the Grinding axis number of Plunge Grinding Cycle(G75).
NOTE
The axis number except for the cutting axis can be specified.
When the axis number which is same to cutting axis is specified,
PS0456 alarm is issued at the time of execution. The Grinding
Cycle is executed when this parameter value is 0, PS0456 alarm
is also issued.
Grinding axis number of Traverse direct constant-size Grinding cycle(G72)
5177
Grinding axis number of Direct Constant Dimension Pulnge Grinding
Cycle(G77)
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 0 to Number of controlled axes
For the Lathe system:
Set the Grinding axis number of Traverse direct constant-size Grinding
cycle(G72).
For the Machining Center system:
Set the Grinding axis number of Direct Constant Dimension Plunge
Grinding Cycle (G77).
NOTE
The axis number except for the cutting axis can be specified.
When the axis number which is same to cutting axis is specified,
PS0456 alarm is issued at the time of execution. The Grinding
Cycle is executed when this parameter value is 0, PS0456 alarm
is also issued.
