4.DESCRIPTION OF PARAMETERS B-63950EN/02

- 160 -

4.17 PARAMETERS OF PROGRAMS

#7 #6 #5 #4 #3 #2 #1 #0

3400 SMX PGD MGC MGO

[Input type] Parameter input

[Data type] Bit path

# 0 MGO If the program restart M/S/T/B code output function is used:

0: When bit 6 (MOA) of parameter No. 7300 is set to 0, the last M

code only is output. When bit 6 (MOA) of parameter No. 7300 is

set to 1, M codes are output in a specified order.

1: When bit 6 (MOA) of parameter No. 7300 is set to 0, the last M

code of each M code group is output. When bit 6 (MOA) of

parameter No. 7300 is set to 1, M codes are output in the order of

groups.

NOTE

This parameter is valid only when the optional M

code grouping function is used and bit 7 (MOU) of

parameter No. 7300 is set to 1.

# 1 MGC When a single block specifies multiple M commands, an M code

group check is:

0: Made.

1: Not made.

# 5 PGD The G10.9 command (programmable diameter/radius specification

switching) is:

0: Disabled.

1: Enabled.

NOTE

1 The option for the dynamic diameter/radius

switching function is required.

2 When the G10.9 command is enabled by this

parameter, signal-based dynamic diameter/radius

switching is disabled.

# 6 SMX An S code specified in a block that specifies G92 (G50 with G code

system A of the T series) is:

0: Regarded as a maximum spindle speed command.

1: Not regarded as a maximum spindle speed command (but

regarded as a spindle speed command).
