SEARCH_GT_DINT Search for greater than DINT data array
SEARCH_GE_BYTE Search for greater than or equal to BYTE data array
SEARCH_GE_WORD Search for greater than or equal to WORD data array
SEARCH_GE_DWORD Search for greater than or equal to DWORD data array
SEARCH_GE_INT Search for greater than or equal to INT data array
SEARCH_GE_UINT Search for greater than or equal to UINT data array
SEARCH_GE_DINT Search for greater than or equal to DINT data array
SEARCH_LT_BYTE Search for less than BYTE data array
SEARCH_LT_WORD Search for less than WORD data array
SEARCH_LT_DWORD Search for less than DWORD data array
SEARCH_LT_INT Search for less than INT data array
SEARCH_LT_UINT Search for less than UINT data array
SEARCH_LT_DINT Search for less than DINT data array
SEARCH_LE_BYTE Search for less than or equal to BYTE data array
SEARCH_LE_WORD Search for less than or equal to WORD data array
SEARCH_LE_DWORD Search for less than or equal to DWORD data array
SEARCH_LE_INT Search for less than or equal to INT data array
SEARCH_LE_UINT Search for less than or equal to UINT data array
SEARCH_LE_DINT Search for less than or equal to DINT data array
Format
SRCH
EQ
(type)
FD
INX
IN
(EN)
??????? ???????
???????
???????
AR
SRCH_NE
SRCH_GT
SRCH_GE
SRCH_LT
SRCH_LE
ONX
???????
LEN
Previous page
Next page
