2.3.2 System references

The following explains the system references used by the PMC control

software.

Address Name Explanation

%S601 #ALW_OFF Always OFF signal.

%S602 #ALW_ON Always ON signal.

%S606 #T_200MS 200 ms cycle signal. (104 ms ON, 96 ms OFF)

%S607 #T_SEC 1 sec cycle signal. (504 ms ON, 496 ms OFF)

%ST57 #STP_RUN STOP to RUN transition signal. Turned ON when the

current scan is the first scan.

%ST58 #RUN_STP

RUN to STOP transition signal. Reset from 1 (ON) to 0

(OFF) when the current scan is the last scan.

%S603 #RUNNING RUN status signal. Turned ON when during RUN.

%SK1 # NEN_OUT Prevents the edit (output) operation of the sequence

program.

%SK2 # EN_PRG Validates the program debugging function.

%SK3 # RUN_NAT Manually (soft key) executes a sequence program.

%SK5 # EN_RAM Enables display of data input on the memory content

display screen.

%SK8 # NEN_DTC The PMC parameter data table control screen is not

displayed.

%SK15 # EN_IN Validates the sequence program edit function.

%SK17 # FROM_AT The ladder program is automatically written to F-ROM

after editing.

%SK19 # DSP_RUN “RUN” or “STOP” soft key is displayed.

%SK23 #HIDEPRM The PMC parameter screen is not displayed.

%SK24 #PROTPRM

The PMC parameter is not changed by reading of the

I/O screen.

%SK49 #EN_OVR The override mode becomes enabled.

%SK54 #TRC_AT Automatically starts the trace function (TRACE) when

the power is turned on.
