Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 260

Additional Manual

Page of 317

/ 317

FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

259/

316

TITLE

DRAW.NO.

%SK00003 0 : The sequence program is executed automatically when the power is turned

on.

#RUN_NAT 1 : The sequence program is executed when the [RUN] soft key is pressed.

%SK00005 0 : Data cannot be entered at the FORCING screen.

#EN_RAM 1 : Data can be entered at the FORCING screen.

%SK00008 0 : The PMC parameter data register table control screen is displayed.

#NEN_DTC 1 : The PMC parameter data register table control screen is not displayed.

%SK00014 0 : The parity of the sequence program is checked.

The parity of the sequence program is not checked.

%SK0001 0 : Allows the edit (output) operation of the sequence program.

#NEN_OUT 1 : Prevents the edit (output) operation of the sequence program.

%SK00015 0 : Prevents the edit (input) operation of the sequence program.

#EN_IN 1 : Allows the edit (input) operation of the sequence program.

%SK00017 0 : The program is not automatically written to F-ROM.

#FROM_AT 1 : After a sequence program has been updated, the program is automatically

written to F-ROM.

%SK00019 0 : Prevents run/stop and edit (input) operation of the sequence program.

#DSP_RUN 1 : Allows run/stop and edit (input) operation of the sequence program.

%SK00023 0 : The PMC parameter screen is displayed.

#HIDEPRM 1 : The PMC parameter screen is not displayed.

%SK00024 0 : The PMC parameter can be changed.

#PRTCPRM 1 : The PMC parameter cannot be changed.

%SK00054 0 : In the trace function, tracing starts when the [EXEC] soft key is pressed.

#TRC_AT 1 : In the trace function, tracing starts automatically when the power is turned

on.

WARNING

Set this bit to 0 before shipment from the factory.

CAUTION

Set to 0 the bit that is not used by PMC control software.
