4.5.8 Bit Set, Clear

4.5.8.1 BIT_SET_BYTE(in, bit, length)

Set a specific bit within a string (consecutive registers) of words by setting that bit to 1.

in: BYTE variable; the first item in the data to be operated on.

bit: INT variable or constant; the bit number of in that will be set. 1 bit (16*length).

length: Constant; the number of words comprising the data string to operate on (1 to 255).

4.5.8.2 BIT_SET_WORD(in, bit, length)

Set a specific bit within a string (consecutive registers) of words by setting that bit to 1.

in: WORD variable; the first item in the data to be operated on.

bit: INT variable or constant; the bit number of in that will be set. 1 bit (16*length).

length: Constant; the number of words comprising the data string to operate on (1 to 255).

4.5.8.3 BIT_SET_DWORD(in, bit, length)

Set a specific bit within a string (consecutive registers) of words by setting that bit to 1.

in: DWORD variable; the first item in the data to be operated on.

bit: INT variable or constant; the bit number of in that will be set. 1 bit (16*length).

length: Constant; the number of words comprising the data string to operate on (1 to 255).

4.5.8.4 BIT_CLR_BYTE(in, bit, length)

Clear a specific bit within a string (consecutive registers) of words by setting that bit to 0.

in: BYTE variable; the first item in the data to be operated on.

bit: INT variable or constant; the bit number of in that will be cleared. 1 bit (16*length).

length: Constant; the number (1 to 255) of words comprising the data string to operate on.

4.5.8.5 BIT_CLR_WORD(in, bit, length)

Clear a specific bit within a string (consecutive registers) of words by setting that bit to 0.

in: WORD variable; the first item in the data to be operated on.

bit: INT variable or constant; the bit number of in that will be cleared. 1 bit (16*length).

length: Constant; the number (1 to 255) of words comprising the data string to operate on.

4.5.8.6 BIT_CLR_DWORD(in, bit, length)

Clear a specific bit within a string (consecutive registers) of words by setting that bit to 0.

in: DWORD variable; the first item in the data to be operated on.

bit: INT variable or constant; the bit number of in that will be cleared. 1 bit (16*length).

length: Constant; the number (1 to 255) of words comprising the data string to operate on.

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
