Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 125

Additional Manual

Page of 317

/ 317

FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

124/

316

TITLE

DRAW.NO.

3.10 PMC Operations

PMC operation instructions

Instruction Function Parameter Data type

Controlled

I/O

PMC_ADD_BCDx

Addition of

BCD data

IN1, IN2, Q BYTE, WORD, DWORD EN, ENO

PMC_SUB_BCDx

Subtraction of

BCD data

IN1, IN2, Q BYTE, WORD, DWORD EN, ENO

PMC_MUL_BCDx Multiplication

of BCD data

IN1, IN2, Q BYTE, WORD, DWORD EN, ENO

PMC_DIV_BCDx Division of

BCD data

IN1, IN2, Q BYTE, WORD, DWORD EN, ENO

PMC_MOD_BCDx

Remainder of

BCD data

IN1, IN2, Q BYTE, WORD, DWORD EN, ENO

R_TRIG

Detection of

rising edge

-- --

EN, ENO,

address

F_TRIG Detection of

falling edge

-- -- EN, ENO,

address

PMC_DECODE_(type) Decode LEN, IN,

BASE, Q

IN/BASE = ANY_INT

LEN/Q = WORD

EN, ENO

PMC_EVPAR_(type) Even parity

check

IN BYTE, WORD, DWORD EN, ENO, Q

PMC_ODPAR_(type)

Odd parity

check

IN BYTE, WORD, DWORD EN, ENO, Q

PMC_WINDOW

Read and write

of CNC

window data

LEN, AR INT

EN, ENO,

Q, ERR

PMC_EXIN

External data

input

HEAD, CMD,

DT

HEAD = INT

CMD = WORD

DT = DWORD

EN, ENO,

Q, ERR

PMC_AXCTL PMC axis

control

GRP, CMD,

DT1, DT2

GRP = INT

CMD = WORD

DT1 = DINT

DT2 = DINT

EN, ENO,

R, Q, ERR
