4.9 IL PMC Operations
PMC Operations
Use these IL functions to operate PMC.
Add BCD
Subtract BCD
Multiply BCD
Divide BCD
Modulus BCD
Trigger
Decode
Even Parity
Odd Parity
Window
EXIN
AXCTL
4.9.1 Add BCD
4.9.1.1 PMC_ADD_BCD2(in1, in2)
accumulator in1 + in2
Add two BCD2 and store the sum in the integer accumulator.
in1: BYTE variable or constant
in2: BYTE variable or constant
4.9.1.2 PMC_ADD_BCD4(in1, in2)
accumulator in1 + in2
Add two BCD4 and store the sum in the integer accumulator.
in1: WORD variable or constant
in2: WORD variable or constant
4.9.1.3 PMC_ADD_BCD8(in1, in2)
accumulator in1 + in2
Add two BCD8 and store the sum in the integer accumulator.
in1: DWORD variable or constant
in2: DWORD variable or constant
