4.4.4 Greater or Equal

4.4.4.1 GE_INT(in1, in2)

If in1 in2, boolean accumulator 1

If in1 < in2, boolean accumulator 0

Compare two single-precision integers. If in1 is greater than or equal to in2, set the boolean accumulator. If in1 is less

than in2, clear the boolean accumulator.

in1: INT variable or constant

in2: INT variable or constant

4.4.4.2 GE_UINT(in1, in2)

If in1 in2, boolean accumulator 1

If in1 < in2, boolean accumulator 0

Compare two single-precision unsigned integers. If in1 is greater than or equal to in2, set the boolean accumulator. If

in1 is less than in2, clear the boolean accumulator.

in1:UINT variable or constant

in2: UINT variable or constant

4.4.4.3 GE_DINT(in1, in2)

If in1 in2, boolean accumulator 1

If in1 < in2, boolean accumulator 0

Compare two double-precision integers. If in1 is greater than or equal to in2, set the boolean accumulator. If in1 is less

than in2, clear the boolean accumulator.

in1: DINT variable or constant

in2: DINT variable or constant

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
