Explanation of options

PROGRAM: Outputs sequence programs only.

PARAMETER: Outputs PMC parameters.

- FILE NO.

FILE NO. is displayed only when “READ,” ”COMPARE,” or “DELETE” is

selected for “FUNCTION.”

Enter the file number in the edit box.

- FILE NAME

FILE NAME is displayed when “WRITE,” “READ,” “COMPARE,” or

“DELETE” is selected for “FUNCTION.”

Enter the file name in the edit box.

When “READ,” “COMPARE,” or “DELETE” is selected for

“FUNCTION,” the file name corresponding to the file number entered in

“FILE NO.” is displayed automatically.

The file name must be in MS-DOS format: a file name of up to 8 characters

followed by an extension of up to 3 characters.

When “WRITE” is selected for “FUNCTION” and the file name is not

entered, the following names are automatically assumed.

DATA KIND File name

LADDER PMCSD7.LAD

PARAM PMCSD7.PRM

Explanation of soft keys

[EXEC]: Executes the function selected for “FUNCTION.” During

execution, the soft key disappears and the [CANCEL]

soft key appears to the right of the key.

[CANCEL]: Cancels the execution of the function. When the function

terminates normally, the soft key disappears.

[LIST]: Replaces the current display with the memory card list

screen. See Section 5.6.3 “Memory Card List Screen” for

details.

The system supports the following memory cards:

O: Supported

X: Not supported

CAUTION

When both “FILE NO.” and “FILE NAME” are displayed at the same time, and a value is entered

for “FILE NO.” and another file name is entered in “FILE NAME,” the value entered in “FILE

NO.” is erased and the file name entered in “FILE NAME” becomes effective.
