3.6.3 BLK_CLR_(type)

Function

When the Block Clear (BLK_CLR) function receives power flow, it fills

the specified block of data with zeros, beginning at the reference

specified by IN. The function passes power to the right whenever power

is received.

BLK_CLR_(type) instructions

Name Explanation

BLK_CLR_BYTE Block clear of BYTE data

BLK_CLR_WORD Block clear of WORD data

BLK_CLR_DWORD Block clear of DWORD data

BLK_CLR_INT Block clear of INT data

BLK_CLR_UINT Block clear of UINT data

BLK_CLR_DINT Block clear of DINT data

Format

BLK_CLR

(type)

(EN) (ENO)

???????

LEN

Parameters

Parameter Data type Meaning

EN BOOL Execution of logical operation

LEN Constant

The number of data to be

cleared, starting at the IN

location. 1<=LEN<=256

IN BYTE,WORD, DWORD Input data

ENO BOOL Returns the value of EN
