FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

71/

316

TITLE

DRAW.NO.

3.5.4 SHIFTL_(type)/SHIFTR_(type)

Function

When EN is set to ON and is receiving the power flow,

SHIFTL/SHIFTR left-shifts/right-shifts the bit string of input

parameter IN by an amount given by input parameter N.

The last bit to overflow is output to output parameter B2, and the value

of input parameter B1 (0 or 1) is replaced with an empty bit. The

shifted bit string is output to output parameter Q.

IN and Q must both be of the same data type. When the value of N is

less than 0, or greater than the number of bits in the bit string of IN,

SHIFTL/SHIFTR stops the power flow.

SHIFTL_(type)/SHIFTR_(type) instructions

Name Explanation

SHIFTL_BYTE Left shift of BYTE data

SHIFTL_WORD Left shift of WORD data

SHIFTL_DWORD Left shift of DWORD data

SHIFTR_BYTE Right shift of BYTE data

SHIFTR_WORD Right shift of WORD data

SHIFTR_DWORD Right shift of DWORD data

Format

SHIFTL

(type)

(EN)

??????? ???????

???????

SHIFTR

Q ???????

LEN
