FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

199/

316

TITLE

DRAW.NO.

4.7.2.3 Operands

Operand Data Type Memory Area Description

Length

Constant

The number of registers starting at ar that make

up the memory block to search. 1 ??

32767.

BOOL %I*, %Q*,%M*,%S*

BYTE %I*, %Q*,%M*,%S*,%R

WORD %I*, %Q*,%M*,%S*,%R

DWORD %I*, %Q*,%M*,%S*,%R

INT %I*, %Q*,%M*,%S*,%R

UINT %I*, %Q*,%M*,%S*,%R

ar (must be the same

data type as in)

DINT %I*, %Q*,%M*,%S*,%R

The starting address of the memory block to

search; the address of the first register in the

memory block.

inx UINT variable or

constant

%I*, %Q*,%M*,%S*,%R

The zero-based index into the memory block at

which to begin the search. Zero points to the

first reference. Valid range: 0 inx (length-

1). If inx is out of range, it is set to the default

value of 0.

BOOL variable or

constant

%I*, %Q*,%M*,%S*

BYTE variable or

constant

%I*, %Q*,%M*,%S*,%R

WORD variable

or constant

%I*, %Q*,%M*,%S*,%R

DWORD variable

or constant

%I*, %Q*,%M*,%S*,%R

INT variable or

constant

%I*, %Q*,%M*,%S*,%R

UINT variable or

constant

%I*, %Q*,%M*,%S*,%R

in (must be the same

data type as ar)

DINT variable or

constant

%I*, %Q*,%M*,%S*,%R

The object of the search; the value to search for.

onx

UINT variable %I*, %Q*,%M*,%S*,%R

The one-based position within the memory

block of the search target. A value of 1 points to

the first reference. Valid range: 1 onx

length.
