FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

316/

316

TITLE

DRAW.NO.

PC090 NMI(___) xxxxxxxx:yyyyyyyy

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

An NMI with an unknown cause occurred in

the PMC management software.

PC092 USER TRAP

aa:xxxxxxxx

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

The TRAP instruction, which is not used in

the PMC management software, was

executed.

PC093 INT(SYS)

xxxxxxxx:yyyyyyyy

PC094 INT(TRAP)

xxxxxxxx:yyyyyyyy

PC095 INT(EX) xxxxxxxx:yyyyyyyy

PC096 INT(IN) xxxxxxxx:yyyyyyyy

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

An interrupt with an unknown cause

occurred in the PMC management software.

PC087 PARITY ERR (LADDER-2)

PC097 PARITY ERR (LADDER)

PC098 PARITY ERR (DRAM)

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

An error occurred in a RAM check.

PC501 NC/PMC INTERFACE ERR

PATH_

1) Replace the master printed

circuit board.

2) If the error recurs even after the

replacement, contact FANUC to

report the status (displayed

message, system configuration,

operation, when the error occurs,

occurrence frequency, etc.).

The reading/writing of signals between the

CNC and the PMC failed.

PC502 ILLEGAL FUNCTION (SUB

xx)

Modify the sequence program so

that instruction function xx is not

used.

Unsupported function instruction xx is used.
