3.10.2 PMC_MOD_BCDx (x = 2, 4, 8)

Function

When EN is set to ON and is receiving the power flow,

PMC_MOD_BCDx divides the BCD data of input parameter IN1 by

that of IN2 (IN1 ÷÷ IN2) and outputs the remainder to output parameter

IN1, IN2, and Q must all be of the same data type.

If invalid BCD data is input to IN, 0 is output to Q. When the operation

ends with no overflow (such as that caused by division by zero), ENO is

set to ON.

Remainder of BCD data

Name Explanation

PMC_MOD_BCD2 Remainder of 2-digit BCD data

PMC_MOD_BCD4 Remainder of 4-digit BCD data

PMC_MOD_BCD8 Remainder of 8-digit BCD data

Format

PMC

MOD

BCD

IN1 Q

IN2

???????

(EN) (ENO)

Parameters

Parameter Data type Meaning

EN BOOL Execution of operation

IN1

BYTE, WORD,

DWORD

Input data 1

IN2 BYTE, WORD,

DWORD

Input data 2

ENO BOOL Normal end flag (set to OFF upon an overflow)

BYTE, WORD,

DWORD

Result of operation
