4.4.3 Greater Than
4.4.3.1 GT_INT(in1, in2)
If in1 > in2, boolean accumulator 1
If in1 in2, boolean accumulator 0
Compare the value of two single-precision integers and set the boolean accumulator to 1 if in1 is numerically greater
than in2. Otherwise, set the boolean accumulator to 0. The accumulator type is set to boolean.
in1: INT variable or constant
in2: INT variable or constant
4.4.3.2 GT_UINT(in1, in2)
If in1 > in2, boolean accumulator 1
If in1 in2, boolean accumulator 0
Compare the value of two single-precision unsigned integers and set the boolean accumulator to 1 if in1 is numerically
greater than in2. Otherwise, set the boolean accumulator to 0. The accumulator type is set to boolean.
in1: UINT variable or constant
in2: UINT variable or constant
4.4.3.3 GT_DINT(in1, in2)
If in1 > in2, boolean accumulator 1
If in1 in2, boolean accumulator 0
Compare the value of two double-precision integers and set the boolean accumulator to 1 if in1 is numerically greater
than in2. Otherwise, set the boolean accumulator to 0. The accumulator type is set to boolean.
in1: DINT variable or constant
in2: DINT variable or constant
For more details, see LD Functions.
Note: IL and LD functions are generally the same, with some differences in data types for operands.
