Fanuc PMC-Model SD7 Programming Manual Additional Manual Page 257

Additional Manual

Page of 317

/ 317

FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

256/

316

TITLE

DRAW.NO.

- If the sequence program can be stopped (STOP state), for example, while it

is being debugged

i) Stop the sequence program.

ii) The parameter protection is released; so data can be entered for them.

An attempt to enter data for protected parameters causes the error message

“WRITE PROTECT” to be displayed. Please refer to "5.4.4.1 Screen for

displaying General settings (GENERAL)".

5.4.2.1 Multiple Data Input

1 This function is effective on the screen of KEEP RELAY and DATA

2 The cursor is moved to the final data position of inputted data.

(1) Input method

- “ ; (EOB)” is used for separating data.

Press the INPUT key after typing “100; 200; 300”.

- “ ; =” is used for inputting the same value as preceding data.

Press the INPUT key after typing “100; =; =; 200; =”, and it

becomes “100, 100, 100, 200, 200”.

- “ ; ;” is used for skipping an input address.

Press the INPUT key after typing “100; ; 100”.

The second data is not inputted.

WARNING

If a sequence program is stopped while the machine is operating, the

machine may behave unexpectedly. Before stopping the sequence

program, make sure that nobody is near the machine and that the tool

cannot interfere with the workpiece or machine. Incorrect operation of

the machine presents an extreme risk of death or serious injury to the

user. Damage the tool, workpiece, and/or the machine is also likely.
