5.4.4.3.5 RAM WRITE ENABLE (%SK5)

If you set ”RAM WRITE ENABLE” to ”YES”, it enables both the forcing

function and the override function.

5.4.4.3.6 DATA REGISTER TABLE CONTROL SCREEN (%SK8)

If you set ”DATA REGISTER TABLE CONTROL SCREEN” to ”NO”, the

data register table control screen does not be displayed.

5.4.4.3.7 HIDE PMC PARAMETER (%SK23)

If you set ”HIDE PMC PARAMETER” to ”YES”, the PMC parameter

screen does not be displayed.

5.4.4.3.8 PROTECT PMC PARAMETER (%SK24)

If you set "PROTECT PMC PARAMETER" to "YES", the PMC parameter

does not change by reading of the I/O screen.

NOTE

The override function also requires the setting of ”OVERRIDE ENABLE”

in the setting parameters (EDIT/DEBUG).

NOTE

Even if this parameter is set to "YES", these settings are invalid if

"PROGRAMMER ENABLE" is set to "YES".

NOTE

Even if this parameter is set to "YES", these settings are invalid if

"PROGRAMMER ENABLE" is set to "YES".
