4.5.3 Logical XOR

4.5.3.1 XOR_BYTE(in1, in2)

accumulator in1 XOR in2

Perform a logical exclusive OR between the bits of in1 and in2 and store the result in the integer accumulator.

Operands: Both in1 and in2 can be either BYTE variables or constants.

4.5.3.2 XOR_WORD(in1, in2)

accumulator in1 XOR in2

Perform a logical exclusive OR between the bits of in1 and in2 and store the result in the integer accumulator.

Operands: Both in1 and in2 can be either WORD variables or constants.

4.5.3.3 XOR_DWORD(in1, in2)

accumulator in1 XOR in2

Perform a logical exclusive OR between the bits of in1 and in2 and store the result in the integer accumulator.

Operands: Both in1 and in2 can be either DWORD variables or constants.

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
