APPENDIX

A Differences Between PMC-SB7

This chapter explains those functions that are supported for the PMC-SB7

but not for the PMC-SD7, as well as those functions which are supported but

with limitations.

A.1 FANUC I/O Link

The following functions are not supported.

- Selectable I/O Link Assignment Function

This function enables the common use of a sequence program for

several machines which have different I/O device configuration with

each other, by setting the parameter to enable/disable each group in

I/O link assignment data.

A.2 Multi-Language Message Display

This function is not supported by the PMC-SD7.

A.3 IEC61131-3 Address Key Input

The reference addresses defined in IEC61131-3 (ex. %I, %IF, %Q) can not

be input by key input. Input all the reference addresses without “%” (ex. I,

IF, Q), and perform a search. (Ex. For trace address input, perform an

address search using the PMCPRM screen)
