3.8.1 (type)_TO_BCDx (x = 4, 8)

Function

When EN is set to ON and is receiving the power flow,

(type)_TO_BCDx converts the integer data of input parameter IN to 4-

or 8-digit BCD, then outputs the result to output parameter Q.

When a large value that can not be expressed in BCD (a value greater

than 9999 for a 4-digit BCD, and greater than 99999999 for an 8-digit

BCD) is input to IN, the maximum value that can be expressed in BCD

(9999 for a 4-digit BCD, and 99999999 for an 8-digit BCD) is output to

Q. In such a case, ENO is not output. Also, if a negative value is input

to IN, 0 is output to Q. Again, in such a case ENO is not output.

(type)_TO_BCDx instructions

Name Explanation

INT_TO_BCD4 Converts from INT to 4-digit BCD

UINT_TO_BCD4 Converts from UINT to 4-digit BCD

DINT_TO_BCD8 Converts from DINT to 8-digit BCD

Format

(type)

BCDx

IN Q

(EN) (ENO)

??????? ???????

Parameters

Parameter Data type Meaning

EN BOOL Execution of conversion

IN ANY_INT Input data

ENO BOOL Normal end flag

Q WORD, DWORD Result of conversion
