4.5.1 Logical AND

4.5.1.1 AND_BYTE(in1, in2)

accumulator in1 AND in2

Perform a logical AND between each bit of in1 and the same bit of in2. The corresponding bit of the integer

accumulator is set or cleared depending on the result.

Operands: Both in1 and in2 can be either a BYTE variable or constant.

4.5.1.2 AND_WORD(in1, in2)

accumulator in1 AND in2

Perform a logical AND between each bit of in1 and the same bit of in2. The corresponding bit of the integer

accumulator is set or cleared depending on the result.

Operands: Both in1 and in2 can be either a WORD variable or constant.

4.5.1.3 AND_DWORD(in1, in2)

accumulator in1 AND in2

Perform a logical AND between each bit of in1 and the same bit of in2. The corresponding bit of the integer

accumulator is set or cleared depending on the result.

Operands: Both in1 and in2 can be either a DWORD variable or constant.

For more details, see LD Functions.

Note: IL and LD functions are generally the same, with some differences in data types for operands.
