FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

86/

316

TITLE

DRAW.NO.

1)Sets the corresponding mask bit in M to 1.

2)Sets the miscompare (MC) output to 1.

3)Updates the output bit string Q to match the new content of mask

string M

4)Sets the bit number output (BN) to the number of the miscompared

bit.

5)Stops the comparison.

MASK_COMP_(type) instructions

Name Explanation

MASK_COMP_BYTE Compare the bits in two BYTE data

MASK_COMP_WORD Compare the bits in two WORD data

MASK_COMP_DWORD Compare the bits in two DWORD data

Format

MASK

CMP

(type)

IN2

(EN)

???????

IN1

BIT???????

LEN

MC ???????

Q ???????

BN ???????

Parameters

Parameter Data type Meaning

EN BOOL Execution of operation.

LEN Constant

The number of data in either

compared string.

1<=LEN<=8192(BYTE)

1<=LEN<=4096(WORD)

1<=LEN<=2048(DWORD)

IN1 ANY Input data 1.

IN2 ANY Input data 2.

M ANY The bit string mask.

BIT UINT The bit number where the next

comparison should start.
