(b) Setting of online connection by NC parameter

You can enable and disable the online connection for Ethernet and RS-232C

by NC parameter No.24 without setting on the PMC online monitor setting

screen. This NC parameter is made effective immediately after setting the

parameter.

If the value of this parameter is changed, the items “RS232-C”and “HIGH

SPEED I/F” in the online monitor screen are automatically changed too.

Please refer to following table.

Contents of NC parameter No.24.

Each item of the online monitor

screen after setting

parameter

No.24

Meanings

RS-232C HIGH SPEED I/F

0 The settings on the online monitor setting screen are effective.

This does not affect “RS-232C”

and “HIGH SPEED I/F”.

Enables “Channel 1 of RS-232C” and disables “HIGH SPEED

I/F”.

USE

(Channel 1)

NOT USE

Enables “Channel 2 of RS-232C” and disables “HIGH SPEED

I/F”.

USE

(Channel 2)

NOT USE

10 Disables “RS-232C” and enables “HIGH SPEED I/F”. NOT USE USE

Enables “Channel 1 of RS-232C” and “HIGH SPEED I/F”. USE

(Channel 1)

USE

Enables “Channel 2 of RS-232C” and “HIGH SPEED I/F”. USE

(Channel 2)

USE

3 to 10

13 to 254

Reserve (Don’t use this setting.)

(Reserved) (Reserved)

255

Terminates communication forcibly.

It is the same effect as soft key [EMG ST].

NOT USE NOT USE

How to set the parameter

(1) Display the No.24 of NC parameter.

(2) To connect by Ethernet, input “10”, “11” or “12”.

(3) To connect by RS-232C, input “1”, “2”, “11” or “12”.

NOTE

ven if the setting of the online monitor screen of PMC is changed, the

value of No.24 in NC parameter is not changed
