Series 21i/210i - Model B Parameter manual Page 136

Parameter manual

Page of 391

/ 391

XB, Z2, and B are dis-

played as axis names.

4. DESCRIPTION OF PARAMETERS

B–63610EN/01

130

(2) Setting for path 2

Parameter 3131x 66 (B). . . . . . . .

Parameter 3131z 0 (2). . . . . . . .

Parameter 3131b 32 (space). . . . . . . .

3132 Axis name (absoulute coordinate) for current position display

3133 Axis name (relative coordinate) for current position display

[Data type] Byte axis

[Valid data range] 0 to 255

These parameters set the axis name for current position display.

When G code system B or C is used, the axis name set in parameter

No.3132 is used for both absolute and relative coordinate axes.

The values set in these parameters are used only for display. For a

command address, the axis name set in parameter No.1020 is used.

When 0 is specified in these parameters, the value set in parameter

No.1020 is used.

3134 Axis display order on workpiece coordinate system screen and workpiece shift screen

[Data type] Byte axis

[Valid data range] 0, 1 to the number of controlled axes

This parameter specifies the order in which axes are displayed on the

workpiece coordinate system screen and workpiece shift screen (for T

series).

When the parameters of all axes are set to 0, all axes are displayed.

When the parameters of some axes are set, the axes for which a value of 0

is specified do not appear. The displayed axes are consecutive without

spaces being left for non–displayed axes.
