B–63610EN/01

4. DESCRIPTION OF PARAMETERS

NOTE

When 0 is set in parameter No.1770 or parameter No.1771,

linear acceleration/deceleration before interpolation is

disabled.

1771 Parameter 2 (for look–ahead control) for setting an acceleration for linear ac-

celeration/deceleration before interpolation (time used to reach the maximum

machining speed during linear acceleration/deceleration before interpolation)

[Data type] Word

[Unit of data] 1 msec

[Valid range] 0 to 4000

This parameter is used to set an acceleration for linear acceleration/

deceleration before interpolation in the look–ahead control mode. In this

parameter, set the time (time constant) used toreach the speed set in

parameter No.1770.

NOTE

1 When 0 is set in parameter No.1770 or parameter No.1771,

linear acceleration/deceleration before interpolation is

disabled.

2 In parameter Nos. 1770 and 1771, set values that satisfy the

following:

Parameter No.1770/Parameter No.1771 y 5

1777

Minimum speed for the automatic corner deceleration function (look–ahead control)

[Data type] Word

[Unit of data, valid range]

Increment system

Unit of data

Valid data range

ncremen

sys

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Set a speed at which the number of buffered pulses in deceleration is

assumed to be 0 when linear acceleration/deceleration before

interpolation is used.

1779

Critical angle subtended by two blocks for automatic corner deceleration (for

look–ahead control)

[Data type] 2–word

[Unit of data] 0.001 deg

[Valid data range] 0 to 180000

Set a critical angle to be subtended by two blocks for corner deceleration

when the angle–basedautomatic corner deceleration function is used.

The angle subtended by two blocks is defined as θ in the examples shown

below.
